VERTICAL CENTER NEXUS 510C-II 5X
MACHINE DESCRIPTION:
The VERTICAL CENTER NEXUS 510C-II 5X 5-axis Vertical Machining Center combines advanced technology, productivity and value for a wide variety of applications. Built on the proven reliability of the VCN-510C platform, with a trunnion style NC rotary table and the MATRIX II CNC full 5 axis contouring in a comprehensive package is easily achieved.
MACHINE CHARACTERISTICS:
- Performance enhancing Intelligent Machine features
- Mx Roller Guide Technology on all axes
- Ergonomic control swings for easy operator viewing
- High accuracy and productivity for a variety of industry applications
- Easy integration of articulated robots for process automation
機床參數(shù)
| Specification | Values | |
|---|---|---|
| 加工能力 | 最大工件直徑 | 533 mm / 21.000 in |
| 最大工件高度 | 305 mm / 12.000 in | |
| 主軸 | 主軸錐度 | 40 |
| 最大轉(zhuǎn)速 | 12000 rpm | |
| 電機功率 (30 分鐘額定) | 11 kw / 15.0 hp | |
| 刀庫 | 刀具數(shù)量 | 30 |
| 進給軸 | 行程(X軸) | 1050 mm / 41.34 in |
| 行程(Y軸) | 510 mm / 20.08 in | |
| 行程(Z軸) | 510 mm / 20.08 in | |
